I have finished this project!! This xbox 360 in a custom pc case uses water cooling to cool the gpu and the cpu processor. It also has mini fans inside to cool the ram chips. All this cooling makes the xbox very very efficient in terms of heat loss. Not much power is drawn to the water cooling system at all. (A thermaltake 745 was used in this project) All the buttons on the case such as the power button is functional and the restart button is now used as the dvd eject system. An Aqua Bay M6 has been installed to moniter the temperature of the cpu and gpu and also moniters the water level in the reservoir. If anythiing is to malfunction or go wrong, it starts to beep loudly. The DVD drive is stealthed so you cant see the dvd drive unless you eject it. See pictures on the page!!!!

 This is my xbox 360 in a PC case, it has ultra violet casing and all buttons functional, like the on/off and restart button is the dvd eject button. ALSO WATER COOLED!!
i have included some pics here: the pictures use photobucket so you might not be able see the pictures if your viewing this in a school, library or any other place that can bloack websites.


IPB Image
^ This pic is at the begining, just a pic of the front of it! ^

IPB Image
^ This pic shows the inside of the case, thats where the xbox 360 motherboard will go. ^

IPB Image
^ ive now inserter motherboard with lots of fand, this is just to test if its going to work and hopwfully find no problems. Im sorry for taking pictures too late. i should have taken one pic at every process. ^

IPB Image
^ Now ive wired the eject button to the restart button on the case it self! ive also now insertered the dvd drive, i still need to put some kind of metal or plastic piece on the botton and top just to round it off. ^

IPB Image
^ Working!! it has come on with the on/off button on the case ^

IPB Image
^ Thats the water cooling radiator fan speed setter. ^

IPB Image
^ a tube has been insterted from the watder block to the the radiator. ^

IPB Image
^ All tubing moreor less complete, i need to now insert the bolts and tighten them up. ^

IPB Image
^ a closer look at it. ^

IPB Image
^ Ive done and clocked it. you can probably see the radiator fan spinning. Now just need to put the casing on! ^


IPB Image
^ FINISHED PRODUCT!!! (time being) clear window says it all. its really fast aswell in terms of speed and more effecient in terms of heat loss also.^

IPB Image
^ Another picture of it from an angle. ^

ive stealthed the dvd drive:(which you all wanted me to do)
IPB Image
that means you cant see it unless you press the eject button!
IPB Image

from the rear:
IPB Image



the sync button was put where the floppy drive goes:
IPB Image



Made a line of light (from the rol) Now you are able to detect wether the xbox is on it not!:
IPB Image



inserted a Aqua Bay M6 to monitor the temp and water level:
IPB Image


have a look through the floppy drive bay, next to the sync button:
IPB Image



From the inside(taken off the front case)
IPB Image


NOW THE BEST THING ABOUT THIS BEAST IS THAT IS ULTRA VIOLET SO WHEN YOU TURN THE LIGHTS OFFF. MAAAAAN IT LOOKS SWEET.
Now when i have my frinds down, they gather round it like its some kind of concor match in primary school or something.

Feel free to comment on the have your say page OR alternativly email me at mighty13@hotmail.co.uk

IM GOING TO PUT IT ON FOR SALE SOON. COMES WITH 3 CONTROLL PADS (1 BLACK, 2 WHITE) WIRELESS. 120 GB INTERNAL hdd, WIFI MODULE AND ALL CABLES.
